INSULATING MAT CATALOGS & LEAFLETS

DURATUF INSULATING MATS CATALOG

Contains complete details on our Indian & International Range of Electrical Insulating Mats including their Technical Information, Comparison, Fixing Guide, FAQ’s & much more…

X-VOLT INSULATING MATS LEAFLET

Contains detailed information on X-VOLT Insulating Mats including Product Pictures, Technical Information, Applications, Fixing Guide & much more…

PRODUCT TECHNICAL DATASHEETS

X-VOLT INSULATING MATS (IS 15652)

Overview | Product Pics | Technical Info | Applications | Ordering Info

SAFEVOLT INSULATION MATS (IS 15652)

Overview | Product Pics | Technical Info | Applications | Ordering Info

ELECTRICAL CHECKER MATS (IS 5424)

Overview | Product Pics | Technical Info | Applications | Ordering Info

ELECTRICAL RUBBER MATS (IEC 61111)

Overview | Product Pics | Technical Info | Applications | Ordering Info

SWITCHBOARD MATS
(ASTM D178)

Overview | Product Pics | Technical Info | Applications | Ordering Info

ELECTRICAL SAFETY MATS (AS/NZS 2978)

Overview | Product Pics | Technical Info | Applications | Ordering Info

OUR OTHER PRODUCT CATALOGS

DURATUF CORPORATE CATALOG

Contains details about our Company, our complete Product Range, Glossary of Rubber Terms, Product Guides, Clientele & much more…

DURATUF RUBBER SHEETS CATALOG

Contains details on our different Rubber Sheets including their Technical Information, Grades, Application, Selection Guide, FAQ’s & much more…

DURATUF RUBBER V-BELTS CATALOG

Contains complete details on our V-Belts including their Applications, Types, Features, Technical Information, Usage Guide, FAQ’s & much more…

Product Code	Class	Thickness	Working Voltage	AC Proof Voltage	Di-electric Strength	Weight per m²
ASTM 001	0	3.2 mm	1.0 KV	5.0 KV	6.0 KV	5.0 Kgs
ASTM 002	1	4.8 mm	7.5 KV	10.0 KV	20.0 KV	7.5 Kgs
ASTM 003	2	6.4 mm	17.0 KV	20.0 KV	30.0 KV	10.0 Kgs
ASTM 004	3	9.5 mm	26.5 KV	30.0 KV	40.0 KV	15.0 Kgs
ASTM 005	4	12.7 mm	36.0 KV	40.0 KV	50.0 KV	20.0 Kgs
ASTM CD (Custom)	-	Upto 25.0 mm	Upto 36.0 KV	Upto 40.0 KV	Upto 50.0 KV	-

Characteristics	Values
	Type-I	Type-II
Material Composition	Elastomer free from any insertion. Typically, a combination of natural rubber and other synthetic polymers.
Antiskid Design	Our standard design is both side antiskid textured surface finish. However, top side fine ribbed design is also available on request.
Tensile strength (T.S.)	4.83 Mpa (min.)
Elongation at Break (E.B.)	250% (min.)
Ageing Properties at 70±1°C for 168 hours.	Tensile strength not less than 50% of original value.
Moisture Absorption	1.5% (max.)	3.0% (max.)
Ozone Resistance (Type IIA)	N.A.	No visible effect.
Flame Resistance (Type IIB)	N.A.	12.7 mm height max. after 30 secs.
Oil Resistance (Type IIC)	N.A.	4% max. volume increase.

Standard Size & Design	1) 1.0 Mtr. Wide x 10.0 Mtr. Long. 2) 1.2 Mtr. Wide x 10.0 Mtr. Long.
Custom Size & Design	Max. width upto 2400mm, length upto 20M and thickness upto 25mm available in Texture Design only.
Standard Colour	Black & Grey without Metallic Derivatives.
Manufacturing Tolerance	±10% on thickness, ±2% on length & width.
Type	Unless specified, insulating matting shall be supplied as per Type I grade. Also available on request, Type II grade (A-Ozone Resistance, B-Flame Resistance, C-Oil Resistance) with combination of all three or individual properties.

Product Code	Class	Recommended Thickness	Max Thickness Allowed	Working Voltage	AC Proof Voltage	Di-electric Strength	Weight per m ²
Both Side Fabric Surface Finish (Standard)
IEC 001	0	2.0 mm	6.0mm	1.0 KV	5.0 KV	10.0 KV	3.2 Kgs
IEC 002	1	2.0 mm	6.0mm	7.5 KV	10.0 KV	20.0 KV	3.2 Kgs
IEC 003	2	3.0 mm	8.0mm	17.0 KV	20.0 KV	30.0 KV	4.8 Kgs
IEC 004	3	3.0 mm	11.0 mm	26.5 KV	30.0 KV	40.0 KV	4.8 Kgs
IEC 005	4	4.0 mm	14.0 mm	36.0 KV	40.0 KV	50.0 KV	6.4 Kgs
IEC CD (Custom)	-	Upto 14.0 mm	Upto 14.0 mm	Upto 36.0 KV	Upto 40.0 KV	Upto 50.0 KV	-
Fine Ribbed Top & Textured Bottom Surface (On Request)
IEC RB 001	0-2	3.0 mm	8.0 mm	17.0 KV	20.0 KV	30.0 KV	4.5 Kgs
IEC RB 002	3-4	5.0 mm	14.0 mm	36.0 KV	40.0 KV	50.0 KV	7.5 Kgs

Characteristics	Values
Material Composition	Elastomer free from any insertion. Typically, a combination of natural rubber and other synthetic polymers.
Mechanical Puncture Resistance	70 N (min.)
Slip Resistance	50 N (min.)
Ageing Properties at 70±2°C for 168 hours.	Mechanical Puncture Resistance not less than 80% of original value.
Flame Retardance	Does not catch fire.
Low Temperature Test at -25±3°C	No visible tear, crack or break.
Acid Resistance	Mechanical Test Values not less than 75% of original value.
Oil Resistance	Mechanical Test Values not less than 75% of original value.
Working Temperature	-25°C to 55°C

Standard Size & Design	1) 1.0 Mtr. Wide x 10.0 Mtr. Long. 2) 1.2 Mtr. Wide x 10.0 Mtr. Long.
Custom Size & Design	Max. width upto 2400mm, length upto 20M and thickness upto 25mm available in Texture Design only.
Standard Colour	Black & Grey without Metallic Derivatives.
Manufacturing Tolerance	±10% on thickness, ±2% on length & width.
