Electrical Insulating Rubber Mats
(As per IEC 61111:2009 & ASTM D178)
Introducing Duratuf Insulating Rubber Matting which is highly electrical resistant and non-conductive in nature. Being non-conductive; these electrical insulation mats protect the electricians, workmen, and operators from any disastrous shocks originating from the high voltage electrical equipment. As they are used in front of switchboards and control panels, they are also often referred to as Switchboard Matting.
Duratuf Electrical Rubber Mats are moisture and water-resistant that guarantees long functional life. Besides, these high voltage insulating mats are also acid, oil, and fire-retardant. The manufacturer’s test certificate is always provided with electrical insulating mats at the delivery time. It is to be noted that colours, cut lengths, and custom shapes are available upon request.
Duratuf is a global high-quality electrical insulation mats supplier and exporter used to protect the operators while they work on electrical installations. Our Electrical Insulating Mats are being used in more than 35+ different countries. These electrical rubber mats are manufactured according to two different International Standards:
- IEC 61111:2009 standard set by the International Electro-Technical Commission
- ASTM D178 standard set by the American Society for Testing and Materials
Our Electrical Insulation Mats Range
[fusion_modal name=”iec-info” title=”Technical Information” size=”large” show_footer=”no”]
Product Code | Class | Recommended Thickness | Max Thickness Allowed | Working Voltage | AC Proof Voltage | Di-electric Strength | Weight per m 2 |
---|---|---|---|---|---|---|---|
IEC 001 | 0 | 2.0 mm | 6.0mm | 1.0 KV | 5.0 KV | 10.0 KV | 3.2 Kgs |
IEC 002 | 1 | 2.0 mm | 6.0mm | 7.5 KV | 10.0 KV | 20.0 KV | 3.2 Kgs |
IEC 003 | 2 | 3.0 mm | 8.0mm | 17.0 KV | 20.0 KV | 30.0 KV | 4.8 Kgs |
IEC 004 | 3 | 3.0 mm | 11.0 mm | 26.5 KV | 30.0 KV | 40.0 KV | 4.8 Kgs |
IEC 005 | 4 | 4.0 mm | 14.0 mm | 36.0 KV | 40.0 KV | 50.0 KV | 6.4 Kgs |
IEC CD (Custom) | - | Upto 14.0 mm | Upto 14.0 mm | Upto 36.0 KV | Upto 40.0 KV | Upto 50.0 KV | - |
IEC RB 001 | 0-2 | 3.0 mm | 8.0 mm | 17.0 KV | 20.0 KV | 30.0 KV | 4.5 Kgs |
IEC RB 002 | 3-4 | 5.0 mm | 14.0 mm | 36.0 KV | 40.0 KV | 50.0 KV | 7.5 Kgs |
Characteristics | Values |
---|---|
Material Composition | Elastomer free from any insertion. Typically, a combination of natural rubber and other synthetic polymers. |
Mechanical Puncture Resistance | 70 N (min.) |
Slip Resistance | 50 N (min.) |
Ageing Properties at 70±2°C for 168 hours. | Mechanical Puncture Resistance not less than 80% of original value. |
Flame Retardance | Does not catch fire. |
Low Temperature Test at -25±3°C | No visible tear, crack or break. |
Acid Resistance | Mechanical Test Values not less than 75% of original value. |
Oil Resistance | Mechanical Test Values not less than 75% of original value. |
Working Temperature | -25°C to 55°C |
Custom Size & Design | Max. width upto 2400mm, length upto 20M and thickness upto 25mm available in Texture Design only. |
Manufacturing Tolerance | ±10% on thickness, ±2% on length & width. |
Standard Colour | Black & Grey without Metallic Derivatives. |
Standard Size & Design | 1) 1.0 Mtr. Wide x 10.0 Mtr. Long. 2) 1.2 Mtr. Wide x 10.0 Mtr. Long. |
Product Code | Class | Thickness | Working Voltage | AC Proof Voltage | Di-electric Strength | Weight per m2 |
---|---|---|---|---|---|---|
ASTM 001 | 0 | 3.2 mm | 1.0 KV | 5.0 KV | 6.0 KV | 5.0 Kgs |
ASTM 002 | 1 | 4.8 mm | 7.5 KV | 10.0 KV | 20.0 KV | 7.5 Kgs |
ASTM 003 | 2 | 6.4 mm | 17.0 KV | 20.0 KV | 30.0 KV | 10.0 Kgs |
ASTM 004 | 3 | 9.5 mm | 26.5 KV | 30.0 KV | 40.0 KV | 15.0 Kgs |
ASTM 005 | 4 | 12.7 mm | 36.0 KV | 40.0 KV | 50.0 KV | 20.0 Kgs |
ASTM CD (Custom) | - | Upto 25.0 mm | Upto 36.0 KV | Upto 40.0 KV | Upto 50.0 KV | - |
Characteristics | Values | |
---|---|---|
Type-I | Type-II | |
Material Composition | Elastomer free from any insertion. Typically, a combination of natural rubber and other synthetic polymers. | |
Antiskid Design | Our standard design is both side antiskid textured surface finish. However, top side fine ribbed design is also available on request. | |
Tensile strength (T.S.) | 4.83 Mpa (min.) | |
Elongation at Break (E.B.) | 250% (min.) | |
Ageing Properties at 70±1°C for 168 hours. | Tensile strength not less than 50% of original value. | |
Moisture Absorption | 1.5% (max.) | 3.0% (max.) |
Ozone Resistance (Type IIA) | N.A. | No visible effect. |
Flame Resistance (Type IIB) | N.A. | 12.7 mm height max. after 30 secs. |
Oil Resistance (Type IIC) | N.A. | 4% max. volume increase. |
Standard Size & Design | 1) 1.0 Mtr. Wide x 10.0 Mtr. Long. 2) 1.2 Mtr. Wide x 10.0 Mtr. Long. |
Custom Size & Design | Max. width upto 2400mm, length upto 20M and thickness upto 25mm available in Texture Design only. |
Standard Colour | Black & Grey without Metallic Derivatives. |
Manufacturing Tolerance | ±10% on thickness, ±2% on length & width. |
Type | Unless specified, insulating matting shall be supplied as per Type I grade. Also available on request, Type II grade (A-Ozone Resistance, B-Flame Resistance, C-Oil Resistance) with combination of all three or individual properties. |
Special Features of Duratuf Electrical Insulating Mats
Why Duratuf Products
We are the leading insulating mat supplier with thousands of satisfied customers all over the globe. Our website provides complete information for buying electrical rubber mats. We supply both the latest Electrical Insulation Mats as per IEC 61111, and the electrical rubber switchboard matting as per ASTM D178 Standard. We have ready stock of a large quantity of electrical insulating mats and can supply these electrical rubber mats anywhere in the world.
On-Time Delivery. Zero Excuse
We ensure delivery on committed time by maintaining a large inventory & short production lead times.
Round the Clock Service
Our team is committed to round the clock customer care to ensure fast resolutions to all queries.
Shortest Resolution Deadline
We at Duratuf Products ensure all customer resolutions are given within 4-48 working hours.
We Are Proud To Export To
Our global market expands over 35+ countries across all the major continents. We ensure fast & on-time delivery through ready-inventories of all our electrical insulating mats.
